Streamline surveillance with the panoramic camera – a single unit that effortlessly replaces the need for three separate cameras. Enjoy comprehensive coverage without the clutter, while saving valuable resources and minimizing installation hassles.
Efficient footage search is now achievable with the panoramic camera. It offers the footage search capabilities of three cameras into a single, user-friendly interface, facilitating post-incident analysis without repeatedly checking images from different angles.
Simplify security systems with the panoramic camera's video analytics. Receive consolidated alerts that combine the insights of three separate cameras into one notification, allowing users to react promptly and effectively without being misled by repeated alerts.
The panoramic camera transforms surveillance infrastructure. Through the installation process of a single camera, users gain complete coverage without the complexities of deploying multiple cameras. This approach saves time and resources without compromising security standards. Not only the above, users only need to purchase one license and a set of accessories, which greatly saves the cost of ownership.
VORTEX cameras effortlessly connect to the cloud, scaling without extra servers. Enjoy peace of mind with up to 10-year warranties and continuous license subscriptions for significant cost savings per camera.
Camera Features
Image Sensor
1/2.7" Progressive CMOS
Resolution
HD 4864 x 1632 (8MP)
SD 2432x 816
Lens Type
Fixed-focal
Focal Length
f = 2.8 mm
Aperture
F1.2
Iris
Fixed iris
Field of View
180° (Horizontal)
50° (Vertical)
180° (Diagonal)
Camera Movement
Tilt: 20°
Shutter Speed
1/30 sec. to 1/32,000 sec.
Day/Night
Yes
IR Cut Filter
Yes
IR Range
20 meters
WDR Technology
WDR Pro
Minimum Illumination
0.018 lux @ F1.2 (Color), 30IRE
<0.01 lux @ F1.2 (B/W)
0 lux with IR illumination on
Onboard Storage
MicroSD/SDHC/SDXC card slot
(Built-in 512GB industrial SD Card)
Standard Video Settings
Frame Rate
15FPS
Video Streaming Settings
HD 4864 x 1632 (8MP)@15fps 3Mbps upload
SD 2432x 816@15fps 400Kbps upload
Standard Audio Settings
Audio
One-way Audio
Interface
Built-in microphone
Effective Range
5 meters
Power and Network
Power Input
IEEE 802.3at PoE Class 4
Power Consumption
Max. 20 W / 13.5W (IR on/ IR off)
Connectivity
RJ-45 cable connector for 10/100 Mbps PoE network connection
Protocols
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users
Up to 6 clients
*Live viewing for 6 clients
*live viewing up to 4 clients and playback 2 clients)
Security
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
Interface
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
General
Operating Temperature
Starting Temperature:
-30°C ~ 55°C (-22°F ~ 131°F)
Working Temperature:
-40°C ~ 55°C (-40°F ~ 131°F) (IR off)
-40°C ~ 50°C (-40°F ~ 122°F) (IR on)
Humidity
90% RH (non-condensing)
Certifications
EMC: CE (EN 55032/EN 55035 Class A), UKCA (BS EN 55032/BS EN 55035 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7, Class A);
Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471), LVD (IEC/EN 62368-1), UKCA (BS EN 62368-1); Environment: IK10 (IEC 62262), IP66(IEC 60529)
Warranty
10 years
Included Accessories
Quick installation guide, alignment sticker, desiccant bag, screw driver, screws pack, sunshield
Mechanical
Weight
1.2 kg
Dimensions
165 x 112 x 119 mm
Body
Metal
AI Analytics
Audio Detection
Yes
Tampering Detection
Yes
People Analytics
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, Profile Search
Vehicle Analytics
Intrusion detection, Line crossing detection, Loitering detection, Attribute Search, Scene Search, Re-Search, LPR Search
Object Analytics
Unattended object detection, Missing object detection
