攝影機在各種光線條件下都能提供極佳的可見度，從明亮的日間到低光環境，均可捕捉到清晰且精確的畫面，確保每個畫面細節均能細膩的呈現。
攝影機能有效平衡影像中亮部與暗部的曝光，提供光線均勻、細節豐富的影像。即使在 LED 背光條件下，也能展現清晰明亮的監控畫面，大幅提升夜間影像表現。
無論光線條件如何，攝影機可在偵測到人或車輛通過時自動啟動補光燈，既可重現清晰的彩色影像，同時保障區域安全。
搭載業界領先的 AI 處理器，攝影機能精確管理視野內超過 25 種偵測物件，並根據物件特徵進行準確識別，不受光線或障礙物影響偵測效果。
VORTEX AI 專為提升監控效率與減少用戶負擔而設計，與傳統動態偵測攝影機相比，能精準辨識異常事件，提供詳細的影片分析及快速搜尋功能，有效降低誤報率，並即時通知管理者，協助其實施有效管理措施。
Camera Features
Image Sensor
1/2.8" Progressive CMOS
Resolution
SD: 1280 x 960
HD: 2560 x 1920
Lens Type
Fixed-focal
Focal Length
f = 2.8 mm
Aperture
F2.0
Iris
Fixed iris
Field of View
103.4° (Horizontal)
75.3° (Vertical)
135.2° (Diagonal)
Camera Movement
Pan: 350° Tilt: 70° Rotate:±175°
Shutter Speed
1/5 sec. to 1/32,000 sec.
Day/Night
Yes
IR Cut Filter
Yes
IR Range
Built-in Warm Light & Infrared (Hybrid) illuminators, effective up to 30 meters with Smart IR/ warm light
WDR Technology
WDR Pro
Minimum Illumination
0.055 lux @ F2.0 (Color)
0.005 lux @ F2.0 (B/W)
0 lux with IR illumination on
Onboard Storage
MicroSD/SDHC/SDXC card slot
(Built-in 256GB industrial SDCard)
Standard Video Settings
Frame Rate
15FPS
Video Streaming Settings
HD Video 2560 x 1920@15fps 1.2Mbps upload
SD Video 1280 x 960@15fps 300Kbps upload
Standard Audio Settings
Audio
One-way Audio
Interface
Built-in microphone
Effective Range
5 Meters
Power and Network
Power Input
IEEE 802.3af PoE Class 3
Power Consumption
Max: 10.7W / 7W (IR on/off)
Normal: 5.5W
Connectivity
RJ-45 cable connector for 10/100 Mbps Network/PoE connection
Protocols
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users
Up to 6 clients
*Live viewing for 6 clients
*live viewing up to 4 clients and playback 2 clients)
Security
"Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
Interface
10 Base-T/100 Base-TX Ethernet
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
General
Operating Temperature
Starting Temperature:
-10°C ~ 50°C (-14°F ~ 122°F)
Working Temperature:
-30°C ~ 50°C (-22°F ~ 122°F) (IR off)
-30°C ~ 45°C (-22°F ~ 113°F) (IR on)
Humidity
90% RH (non-condensing)
Certifications
EMC:
CE (EN 55032/EN 55035 Class A), UKCA (BS EN 55032/BS EN 55035 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7, Class A)
Safety:
UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471), LVD (IEC/EN 62368-1), UKCA (BS EN 62368-1)
Environment:
IK10 (IEC 62262), IP66 (IEC 60529)
IA:
BSMI (EMC: CNS 15936, Safety: CNS 15598-1)"
Warranty
Up to 10 years (Depends on license type)
Included Accessories
Quick installation guide, alignment sticker, screw pack, cable gland
Mechanical
Weight
730 g
Dimensions
ø 120 x 95 mm
Body
Metal
AI Analytics
Audio Detection
Yes
Tampering Detection
Yes
Application
Intrusion detection, Line crossing detection, Loitering detection, Unattended object detection, Missing object detection
Application with xPro License
AI Hub (Attribute search, Scene search, Re-search, Profile search, LPR search, Think search, Event insight), Facial recognition
Application Available with Advanced AI License
Personal protective equipment, Fall detection, Think alert, License plate recognition
